Special lifting machine for four wheel positioning
ZHZY-3.5F
Main technical parameters
Lifting capacity
Main engine4000kg; Auxiliary jack2500kg
lifting height
Main engine1750mm; Auxiliary jack390mm
lifting time
60S
power and motor
3ph:3.0kw,220v /380v,50/60hz
1ph:3.0kw,2p,220v,50/60hz
Air supply pressure
0.6~0.8MPA
Rated oil pressure
25mpa-28mpa
overall weight
2300kg
1、With electric hydraulic stations of bipolar auxiliary jack.
2、Hydraulic synchronous control, synchronization precision.
3、The hydraulic system adopts Italy electromagnetic valve and imports of seal, ensure the stability and service life of the machine:
4、This machine is composed of a machine frame、hydraulic system、
pneumatic system and electric system is composed of four parts.
5、Can be matched with various locating turntable .
